| Technical Parameter |
| Size | 1850*415*1135mm |
| Wheelbase | 1355mm |
| Weight | 58kg(Battery not included) |
| Voltage Value | 48V |
| Charging power | 220V50HZ |
| Double brace height from ground | 120mm |
| Double support angle | 11° |
| Min ground clearance | 155mm |
| Seat height from ground | 770mm |
| Pedal length and width | 295*415mm |
| Cushion length | 665mm |
| Max load | 200KG |
| Climbing ability | 17 degrees |
| Basic configuration |
| Motor | 10”48V27H |
| Voltage Value | 48/60V |
| Rated Power | 600W/800W |
| Peak Power | 1200W/1500W |
| RPM | 550rpm |
| vax speed | 40-50km/h |
| current limit | 30A |
| Other |
| Rim Size | MT10*2.15 |
| Tyres | 3.00-10 |
| Brake | front disc/rear drum |
| Braking mode | Front handbrakes/rear
handbrakes |
| Packaging |
| Packaging Materials | Iron frame + cardboard box |
| Packing size | 1700*570*860 |
| 40HQ cabinet hold | 84 |
| Battery specifications |
| Lead-acid battery maximum capacity | 60V30A |
| Lithium battery maximum dimensions | 190*190*360 |
